Unfortunately, the https://www.gigabyte.com/Motherboard/X570-AORUS-MASTER-rev-11-12 is only partially supported by the Linux Kernel. Not all sensors are accessible because of the lack of a specific driver for one of the two Super I/O chips.
So I’ve asked Gemini what I can do about it, but the proposed solution sounds a little risky to me, considering this computer and CachyOS are my daily drivers since quite a while now.
I’d even say CachyOS is GOAT
Gemini wants me to install this package/driver from the AUR:
# Assuming you have an AUR helper like 'paru' or 'yay'
paru -S it87-dkms
Well, I try not to install too much sh*t from the AUR, but I guess that’s gonna be okay…?
Then it says “You must prevent the kernel from blocking the driver due to resource conflicts.”
/etc/modprobe.d/it87.conf
options it87 ignore_resource_conflict=1
Finally I would apply a new Kernel Parameter in my /boot/limine.conf
:CachyOS
PROTOCOL=linux
KERNEL_PATH=boot:///vmlinuz-linux-cachyos
MODULE_PATH=boot:///initramfs-linux-cachyos.img
# Add the parameter at the end of the existing command line:
KERNEL_CMDLINE=root=UUID=your-uuid-here rw rootflags=subvol=@ acpi_enforce_resources=lax
Gemini issues this warning. That’s why I’m seeking advice from real humans
Stability: Since this relies on it87-dkms (a community-maintained driver), there is a small risk that a major kernel update could break the module compilation. If your sensors disappear after a system update, simply rebuild the DKMS modules (sudo dkms autoinstall).
Do you think this procedure is safe? I don’t want to lose all the nice optimizations tweaks of the CachyOS-Kernel.
Below is the output of “sensors” it’s missing quite a lot and some values seem wrong. I have to two thermistor sensors to check water temps.
it8792-isa-0a60
Adapter: ISA adapter
in0: 1.78 V (min = +0.00 V, max = +2.78 V)
in1: 719.00 mV (min = +0.00 V, max = +2.78 V)
in2: 981.00 mV (min = +0.00 V, max = +2.78 V)
in3: 76.00 mV (min = +0.00 V, max = +2.78 V)
in4: 1.78 V (min = +0.00 V, max = +2.78 V)
in5: 1.18 V (min = +0.00 V, max = +2.78 V)
in6: 2.78 V (min = +0.00 V, max = +2.78 V) ALARM
3VSB: 3.33 V (min = +0.00 V, max = +5.56 V)
Vbat: 3.07 V
fan1: 1634 RPM (min = 10 RPM)
fan2: 867 RPM (min = 0 RPM)
fan3: 875 RPM (min = 0 RPM)
temp1: +47.0°C (low = +127.0°C, high = +127.0°C) sensor = thermistor
temp2: +30.0°C (low = +127.0°C, high = +127.0°C) sensor = thermistor
temp3: +47.0°C (low = +127.0°C, high = +127.0°C) sensor = thermistor
pwm1: 44% (freq = 23437 Hz) MANUAL CONTROL
pwm2: 46% (freq = 23437 Hz) MANUAL CONTROL
pwm3: 46% (freq = 23437 Hz) MANUAL CONTROL
intrusion0: ALARM
r8169_0_700:00-mdio-0
Adapter: MDIO adapter
temp1: +51.0°C (high = +120.0°C)
nvme-pci-0100
Adapter: PCI adapter
Composite: +50.9°C (low = -273.1°C, high = +81.8°C)
(crit = +84.8°C)
Sensor 1: +50.9°C (low = -273.1°C, high = +65261.8°C)
Sensor 2: +54.9°C (low = -273.1°C, high = +65261.8°C)
acpitz-acpi-0
Adapter: ACPI interface
temp1: +16.8°C
temp2: +16.8°C
iwlwifi_1-virtual-0
Adapter: Virtual device
temp1: +46.0°C
k10temp-pci-00c3
Adapter: PCI adapter
Tctl: +49.4°C
Tccd1: +45.8°C
Tccd2: +39.5°C
nvme-pci-0400
Adapter: PCI adapter
Composite: +51.9°C (low = -273.1°C, high = +81.8°C)
(crit = +84.8°C)
Sensor 1: +51.9°C (low = -273.1°C, high = +65261.8°C)
Sensor 2: +57.9°C (low = -273.1°C, high = +65261.8°C)
